Unleash the Full Power of AX3000
- New Generation Dual Band Wi-Fi 6: 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz.
- Dual-Core Ultra CPU: Combined with 512MB RAM and 256MB ROM, delivers ultra-fast network performance and quick response.
- Connect Numerous Devices: Powered by OFDMA and BSS Coloring, delivers up to 4× greater network efficiency.
- Full Extra High-Power Amplifier: Extra 4× High-Power FEM amplifier for Stronger Signal and Maximized Coverage.
- Dual WAN Access for Super-Gigabit: Enjoy dual broadband access with combined Speed 1 + Speed 2, delivering true Super-Gigabit performance.
- EasyMesh Compatible: Flexible creation of Mesh network for whole-home coverage by connecting to EasyMesh compatible router.
-
Wi-Fi Up to 3000 Mbps -
Stronger Signal Maximized Coverage
-
Dual-Core Ultra CPU 512M RAM & 256M ROM
-
Dual WAN Network Access
-
USB 3.0
Product datasheet
-
WIRELESS
Standards and ProtocolsWi-Fi 6
- IEEE 802.11ax/ac/n/a 5 GHz
- IEEE 802.11ax/n/b/g 2.4 GHz
Wi-Fi SpeedsDual Band AX3000
- 5 GHz: 2402 Mbps (802.11ax, HE160)
- 2.4 GHz: 574 Mbps (802.11ax)
Wi-Fi Range-
4× Fixed High-Performance Antennas
?Multiple antennas form signal enhancement array to cover larger area
-
Beamforming
?Focus wireless signal strength to clients to extend Wi-Fi range
-
Built-in FEM and Extra 4× High Power FEM
?Increase transmission power and enhance signal coverage
Wi-Fi Capacity-
2×2 MU-MIMO
?Communicate with multiple MU-MIMO clients simultaneously
-
4× Streams
?Connect your devices to more bandwidth
-
Airtime Fairness
?Improve network efficiency by limiting overuse
-
DFS
?Access an extra band to reduce congestion
-
LDPC
?Improve the fault tolerance and reliability of data transmission
Wi-Fi Enhanced Capacity-
160MHz
?Expand bandwidth to 160MHz, providing a larger data transmission channel
-
OFDMA
?Communicate with multiple Wi-Fi 6 clients simultaneously
-
BSS Coloring
?Reduce co-channel interference and improve transmission stability
-
Longer Symbol
?Improve connection stability over long distances or in complex environments
Working Modes- Router Mode
- Access Point Mode (Slave Router in Mesh Mode)
-
SECURITY
Wi-Fi Encryption- WPA3
- WPA2/WPA3
- WPA2
- WPA/WPA2
Network SecurityHomeGuard Security
- SPI Firewall
- Intrusion Prevention
- DDoS Protection
- Malicious Site Blocking
- Access Control
- IP & MAC Binding
- Real-Time IoT Protection
- Network Scanning
- Application Layer Gateway
- Smart Diagnostics
Guest Network- 1× 5 GHz Guest Network
- 1× 2.4 GHz Guest Network
VPN Client- OpenVPN
- PPTP
- L2TP
- WireGuard
VPN Server- OpenVPN
-
HARDWARE
Chips- Ultra Dual Core
DDR/RAM- 512M
Flash/ROM- 256M
Ethernet Ports- 4× Gigabit Adaptive WAN / LAN Ports
Buttons- WPS, Wi-Fi On/Off, Reset, Power On/Off
- DCin
Power- 12V/ 1A
USB1× USB 3.0
- Apple Time Machine
- FTP Server
- Media Server
- Samba Serve
-
SOFTWARE
Easy Mesy-
OneMesh Supported
?Support up to 10 JETON TECH mesh routers through WPS/APP/wired connection
Quality of ServiceIntelligent Acceleration by Device
IPTV- IGMP Proxy
- IGMP Snooping
- Bridge
- Tag VLAN
Parental Controls- Custom Profiles
- Access time control
- Start/End Time
- Week time
- URL Filter
TWT power saving- Smarter Energy Saving with Target Wake Time
Signal Strength Control- Extra Mode
- Standard Mode
- Sleeping Mode
Protocols- IPv4
- IPv6
WAN Types- Dynamic IP
- Static IP
- PPPoE
NAT Forwarding- Virtual Servers
- Port Forwarding
- Port Triggering
- DMZ
- UPnP
DHCP- Address Reservation
- DHCP Client List
- Server
DDNS- Supported
Cloud Service- Auto Firmware Upgrade
- Local cloud management in Russia
Management FeaturesCloud Remote Control and Local Control
- JetNet App
- Web Page
-
-
TEST DATA
Wi-Fi Transmission Power- < 20 dBm, < 100 mW
Wi-Fi Reception Sensitivity-
2.4 GHz
?11ac VHT20_MCS0: -96 dBm
11ac VHT20_MCS8: -73 dB
11ac VHT40_MCS0: -93 dBm
11ac VHT40_MCS9: -68 dB
11ax HE20_MCS0: -96 dBm
11ax HE20_MCS11: -66 dBm
11ax HE40_MCS0: -93 dBm
11ax HE40_MCS11: -63 dBm -
5 GHz
?11ac VHT20_MCS0: -95 dBm
11ac VHT20_MCS8: -72 dBm
11ac VHT40_MCS0: -93 dBm
11ac VHT40_MCS9: -67 dBm
11ac VHT80_MCS0: –89 dBm
11ac VHT80_MCS9: –64 dBm
11ac VHT160_MCS0: –87 dBm
11ac VHT160_MCS9: –61 dBm
11ax HE20_MCS0: –96 dBm
11ax HE20_MCS11: –66 dBm
11ax HE40_MCS0: –93 dBm
11ax HE40_MCS11: –63 dBm
11ax HE80_MCS0: –91 dBm
11ax HE80_MCS11: –61 dBm
11ax HE160_MCS0: –87 dBm
11ax HE160_MCS11: –58 dBm
-
OTHER
CertificationsEAC, RoHS
LanguagesRussian, English, Chinese
System RequirementsInternet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
EnvironmentWorking Temperature: -30~+60°C
Working Humidity:5~95%(non-condensing)
Storing Temperature: -40~+85°C
Storing Humidity:5~ 95% (non-condensing)
Dimensions (W×D×H)199.91×156.8×43.52 mm
Package Content- Wi-Fi Router Jeton AX3000 Ultra
- Power Adapter
- RJ45 Ethernet Cable
- Quick Installation Guide
Highlights
High-Speed Wi-Fi Performance
Enjoy ultra-fast dual-band speeds — 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz.
With 160 MHz bandwidth and 1024-QAM, performance on 5 GHz is 2× faster than Wi-Fi 6 AX1500 and 3× faster than Wi-Fi 5 AC1200.
Dual WAN Access for Super-Gigabit Speed
Enjoy dual broadband access with combined Speed 1 + Speed 2, delivering true Super-Gigabit performance.
Automatically switches between WAN1 and WAN2 within seconds—ensuring uninterrupted live strea-ming, video conferencing, and gaming.
Intelligently balances traffic across devices, especially ideal for smart homes with multiple cameras and always-on IoT devices.
Dual-Core Ultra CPU + 512M RAM
The dual-core Ultra CPU, combined with 512MB RAM and 256MB ROM, delivers ultra-fast network performance and quick response, while provid-ing ample space for future expansion.
Even under heavy multi-device and multi-tasking scenarios, it ensures exceptional stability and ultra-low latency.
Full Extra High-Power Amplifier for Stronger Signal and Maximized Coverage
4× high-performance antennas, and beam-forming technology combine to provide strong signal
Extra 4× High-Power FEM amplifier extend coverage up to 230m
