Product introduction

1*GE WAN+ 3* FE LAN+ WiFi 5 (AC1200)

  • High Speed Dual Band Wi-Fi 5: 867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz.
  • Multiple Devices with MU-MIMO: Establish multiple  connections through 2×2 MU-MIMO for higher speed and greater stability.
  • Stronger Signal & Wider Coverage: 4× high-performance antennas  and beam-forming technology combine to provide stronger signal and wider coverage.
  • Up to 1 Gigabit WAN Port: Ideal for telecom operator packages exceeding 100Mbps
  • EasyMesh Compatible: Flexible creation of Mesh network for whole-home coverage by connecting to EasyMesh compatible router.
  • Management Functions: WEB/TELNET/CLI/TR069.
  • Product icon (23)
    Wi-Fi Up to 1167 Mbps
  • Product icon (18)
    Stronger Signal Wider Coverage
  • Product icon (32)
    Gigabit WAN Ports
  • Product icon (35)
    EasyMesh
  • Product icon (7)

Product datasheet

  • Description

    Model
    • JR1200AC
    Product Name
    • AC1200 Wi-Fi 5 Router
    Product Description
    • 1*GE WAN+ 3*FE LAN + WiFi 5(AC1200)
    Accessories
    • AC-DC power adaptor: DC12V/1A

  • Hardware Parameter

    Dimension
    • 179.9mm×104.1mm×30.8mm(L×W×H)
    Net Weight
    • 200g
    Operating Condition
    •  Operating Temp: -30 ~ +60°C
    •  Operating Humidity: 5 ~ 95%(non-condensed)
    Storing Condition
    •  Storing temp: -40 ~ +85°C
    •  Storing humidity: 5 ~ 95%  (non-condensed)
    Power Adapter
    • DC 12V, 1 A, external AC-DC power adaptor
    Power Supply
    • ≤12W
    Interface
    • 1GE WAN+3FE LAN
    Button
    • Reset/WPS
    Indicators
    • SYS

  • Interface parameter

    Wi–Fi interface
    •  Compliant with IEEE 802.11b/g/n/ac Wi-Fi 5
    •  Wi-Fi: Dual Band, 5GHz & 2.4GHz, rate up to 1167 Mbps,Multiple SSID
    •  5GHz up to 867 Mbps, 2.4GHz up to 300 Mbps
    •  TX power: 5GHz ＜20 dBm; 2.4GHz ＜20 dBm
    Antenna
    • 2.4GHz:2*2, 5GHz :2*2, 4*external antennas
    WAN Interface
    • 1*GE：1*10/100/1000 Mbps RJ45 connectors
    LAN Interface
    • 3*10/100Mbps RJ45 connectors

  • Product Feature

    WIFI
    •  Wi-Fi 5: 802.11a/n/ac 5GHz & 802.11b/g/n 2.4GHz
    •  Support Multi-SSID
    •  Wi-Fi Encryption:WPA-PSK(TKIP)/WPA2-PSK(AES)
    •  Support DSSS, CCK and OFDM
    •  Support BPSK, QPSK, 16QAM and 64QAM
    •  Support OneMesh
    DHCP
    • Support DHCP Server & DHCP Relay
    QoS
    • Support Smart QoS
    Multicast
    •  Support IGMP Snooping(IGMPv1/v2/v3)
    •  Support IGMP Proxy
    •  Support MLD Snooping(MLDv1、MLDv2)
    •  Support MLD Proxy
    •  Support fast leave
    Security
    •  Support Access Control
    •  Support Filtering Based on IP/URL
    •  Support DDoS Protection
    •  Support Port Scanning
    •  Support Anti-Intranet ARP
    •  Support Parent control
    L3
    •  Support IPv4,IPv6 ,IPv4/IPv6 dual stack
    •  Support DHCP/PPPOE/Static IP
    •  Support Static route,NAT
    •  Support DMZ, ALG,UPnP
    •  Support Virtual Server
    •  Support NTP
    •  Support DNS
    Management
    •  Support TR-069
    •  Support WEB
    •  Support TELNET
    •  Support CLI
