Product introduction

Upgrade Your PC’ Wi-Fi with AC1300

  • High Speed Wi-Fi Up to 1300 Mbps: 866 Mbps (5 GHz) + 400 Mbps (2.4 GHz).
  • Dual Band Wireless: 2.4 GHz and 5 GHz allow your devices to access dual band Wi-Fi routers for faster speeds and greater range.
  • MU-MIMO Technology: Improve overall your network throughput and efficiency with MU-MIMO.
  • Powerful Reception Range: Connect to stronger Wi-Fi over wider range with built-in FEM, 2× high-gain antennas and beam-forming.
  • Super Speed USB 3.0:  10× faster transfer speeds than USB 2.0.
  • The Simplest Setup: Pre-installed Driver for Windows 11/10/8.1/8/7/Vista/XP.
  • Product icon (7)
    Wi-Fi Up to 1300 Mbps
  • Product icon (5)
    Dual Band 5G+ 2.4G
  • Product icon (3)
    Built-in FEM
  • Product icon (6)
    USB 3.0
  • Product icon (9)
    Pre-installed Driver

Product datasheet

  • HARDWARE FEATURES

    Antenna

    2× External Fixed High-Performance Antennas

    Interface

    USB 3.0 Connector

    LED

    Status

    Dimensions (W×D×H)

    82.5×36×10 mm

  • WIRELESS FEATURES

    Wireless Standards

    Compatible with 802.11ac/b/g/n

    Frequency Range

    Dual Band: 2.4G & 5G

    Signal Rate
    • 5 GHz

      ?

      Up to 867 Mbps(dynamic)

    • 2.4 GHz

      ?

      Up to 400 Mbps(dynamic)

    Wireless Security

    WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)

    Modulation Technique

    OFDM/CCK

    16-QAM/64-QAM/256-QAM

    Transmission Power

    < 20 dBm

  • SOFTWARE CAPABILITY

    Support Operating System

    Windows XP/Vista/ Win 7/Win 8 /Win8.1 /Win10/Win11

    Software Support

    Pre-installed Driver

  • OTHERS

    Certification

    EAC, RoHS

    Environment

    Working Temperature: -20ºC to 70ºC,

    Storing Temperature: -40ºC to 90ºC

    Working Humidity: 5% to 95% (non-condensing)

    Storing Humidity: Max. 90% (non-condensing)

    Package Content

    Jeton Link W1300 Plus Wireless USB Adapter

    Quick Installation Guide

Highlights

5400 1

Stronger Signal & Wider Reception Range

Stronger Wi-Fi with wider range via built-in FEM, dual high-gain adjustable antennas, and beamforming.

5400 2

Super Speed USB 3.0

10× faster than USB 2.0 , compatible with USB 2.0.

Simplesetup

The Simplest Setup

Just plug and use.

Contact support for any product issues.
